Checkout Capability¶

Capability Name: dev.ucp.shopping.checkout

Overview¶

Allows platforms to facilitate checkout sessions. The checkout has to be finalized manually by the user through a trusted UI unless the AP2 Mandates extension is supported.

The business remains the Merchant of Record (MoR), and they don't need to become PCI DSS compliant to accept card payments through this Capability.

Flow overview¶

High-level checkout flow sequence diagram

Payments¶

Payment handlers are discovered from the business's UCP profile at /.well-known/ucp and checkout.ucp.payment_handlers. The handlers define the processing specifications for collecting payment instruments (e.g., Google Pay, Shop Pay). When the buyer submits payment, the platform populates the payment.instruments array with the collected instrument data.

The payment object is optional on checkout creation and may be omitted for use cases that don't require payment processing (e.g., quote generation, cart management).

Fulfillment¶

Fulfillment is modelled as an extension in UCP to account for diverse use cases.

Fulfillment is optional in the checkout object. This is done to enable a platform to perform checkout for digital goods without needing to furnish fulfillment details more relevant for physical goods.

Checkout Status Lifecycle¶

The checkout status field indicates the current phase of the session and determines what action is required next. The business sets the status; the platform receives messages indicating what's needed to progress.

       +------------+                         +---------------------+
       | incomplete |<----------------------->| requires_escalation |
       +-----+------+                         |   (buyer handoff    |
             |                                |  via continue_url)  |
             | all info collected             +----------+----------+
             v                                           |
    +------------------+                                 |
    |ready_for_complete|                                 |
    |                  |                                 |
    | (platform can    |                                 | continue_url
    | call Complete    |                                 |
    |   Checkout)      |                                 |
    +--------+---------+                                 |
             |                                           |
             | Complete Checkout                         |
             v                                           |
   +--------------------+                                |
   |complete_in_progress|                                |
   +---------+----------+                                |
             |                                           |
             +-----------------------+-------------------+
                                     v
                               +-------------+
                               |  completed  |
                               +-------------+

                               +-------------+
                               |  canceled   |
                               +-------------+
          (session invalid/expired - can occur from any state)

Status Values¶

incomplete: Checkout session is missing required information or has issues that need resolution. Platform should inspect messages array for context and should attempt to resolve via Update Checkout.
requires_escalation: Checkout session requires information that cannot be provided via API, or buyer input is required. Platform should inspect messages to understand what's needed (see Error Handling below). If any recoverable errors exist, resolve those first. Then hand off to buyer via continue_url.
ready_for_complete: Checkout session has all necessary information and platform can finalize programmatically. Platform can call Complete Checkout.
complete_in_progress: Business is processing the Complete Checkout request.
completed: Order placed successfully.
canceled: Checkout session is invalid or expired. Platform should start a new checkout session if needed.

Error Handling¶

The messages array contains errors, warnings, and informational messages about the checkout state. ucp.status is the shape discriminator — "success" means the response carries the expected payload, "error" means it carries error information instead. The severity field on each error message prescribes the recommended action:

Severity	Meaning	Platform Action
`recoverable`	Platform can resolve by modifying inputs via API	Update resource and retry
`requires_buyer_input`	Business requires input not available via API	Hand off via `continue_url`
`requires_buyer_review`	Buyer review and authorization is required	Hand off via `continue_url`
`unrecoverable`	No resource exists to act on	Retry with new resource or inputs, or hand off via `continue_url`

Errors with requires_* severity contribute to status: requires_escalation. Both result in buyer handoff, but represent different checkout states.

requires_buyer_input means the checkout is incomplete — the business requires information their API doesn't support collecting programmatically.
requires_buyer_review means the checkout is complete — but policy, regulatory, or entitlement rules require buyer authorization before order placement (e.g., high-value order approval, first-purchase policy).

When the business cannot create a new resource or the requested resource no longer exists, the response contains ucp.status: "error" with messages describing the failure — no resource is included in the response body. When no resource exists to act on, messages SHOULD use severity: "unrecoverable". For example, a business may reject a create checkout request where all items are unavailable:

{
  "ucp": { "version": "2026-01-11", "status": "error" },
  "messages": [
    {
      "type": "error",
      "code": "out_of_stock",
      "content": "All requested items are currently out of stock",
      "severity": "unrecoverable"
    }
  ],
  "continue_url": "https://merchant.com/"
}

See REST and MCP binding examples.

Error Processing Algorithm¶

When status is incomplete or requires_escalation, platforms should process errors as a prioritized stack. The example below illustrates a checkout with three error types: a recoverable error (invalid phone), a buyer input requirement (delivery scheduling), and a review requirement (high-value order). The latter two require handoff and serve as explicit signals to the platform. Businesses SHOULD surface such messages as early as possible, and platforms SHOULD prioritize resolving recoverable errors before initiating handoff.

{
  "status": "requires_escalation",
  "messages": [
    {
      "type": "error",
      "code": "invalid_phone",
      "severity": "recoverable",
      "content": "Phone number format is invalid"
    },
    {
      "type": "error",
      "code": "schedule_delivery",
      "severity": "requires_buyer_input",
      "content": "Select delivery window for your purchase"
    },
    {
      "type": "error",
      "code": "high_value_order",
      "severity": "requires_buyer_review",
      "content": "Orders over $500 require additional verification"
    }
  ]
}

Example error processing algorithm:

GIVEN response with messages array

FILTER errors FROM messages WHERE type = "error"

PARTITION errors INTO
  recoverable           WHERE severity = "recoverable"
  requires_buyer_input  WHERE severity = "requires_buyer_input"
  requires_buyer_review WHERE severity = "requires_buyer_review"
  unrecoverable         WHERE severity = "unrecoverable"

IF unrecoverable is not empty
  RETRY with new resource or inputs, or hand off via continue_url
  RETURN

IF recoverable is not empty
  FOR EACH error IN recoverable
    ATTEMPT to fix error (e.g., reformat phone number)
  CALL Update Checkout
  RETURN and re-evaluate response

IF requires_buyer_input is not empty
  handoff_context = "incomplete, additional input from buyer is required"
ELSE IF requires_buyer_review is not empty
  handoff_context = "ready for final review by the buyer"

Standard Errors¶

Standard errors are standardized error codes that platforms are expected to handle with specific, appropriate UX rather than generic error treatment.

Code	Description
`out_of_stock`	Specific item or variant is unavailable
`item_unavailable`	Item cannot be purchased (e.g. delisted)
`address_undeliverable`	Cannot deliver to the provided address
`payment_failed`	Payment processing failed
`eligibility_invalid`	Eligibility claim could not be verified at completion

Businesses SHOULD mark standard errors with severity: recoverable to signal that platforms should provide appropriate UX (out-of-stock messaging, address validation prompts, payment method changes) rather than generic error messages or deferring to checkout completion.

Example: out_of_stock requires specific upfront UX, whereas payment_required can be handled generically at submission.

Eligibility Verification at Completion¶

Platforms provide context.eligibility — buyer claims about eligible benefits such as loyalty membership, payment instrument perks, and similar. These are claims, not verified facts. Businesses MAY act on recognized claims during the session (adjusting pricing, granting product access, applying provisional discounts), but all accepted claims MUST be resolved before the transaction can complete.

Unrecognized or inapplicable claims MUST NOT block the checkout. Businesses SHOULD notify the buyer via messages with type: "warning" when a claim is not accepted, and MAY use type: "info" to explain the effects of accepted claims. At completion, accepted claims that remain unverified MUST result in type: "error" with code: "eligibility_invalid" (see below).

Eligibility message codes:

Type	Code	When
`warning`	`eligibility_not_accepted`	Claim not recognized or not applicable
`info`	`eligibility_accepted`	Effect of an accepted claim
`error`	`eligibility_invalid`	Accepted claim could not be verified at completion

A claim is resolved when it is either verified or rescinded:

Verified: The Business confirms the claim against a proof provided at completion time. UCP does not prescribe how verification occurs — proof may come from the payment credential, an identity verification capability, or any other mechanism negotiated between Platform and Business.
Rescinded: The Platform removes the claim from context.eligibility before completion (e.g., buyer changes payment method, withdraws a membership claim). Once removed, the Business recalculates without it.

Businesses MUST NOT complete a transaction with unresolved eligibility claims. Unverified claims may result in incorrect pricing or unauthorized access to restricted products.

When verification fails:

Verification failure MUST only affect the messages array. The Business MUST return an error in messages with code: "eligibility_invalid" and severity: "recoverable". Messages SHOULD use the path field to identify which specific claim(s) could not be verified. The Platform MAY then provide valid proof and resubmit, restructure the checkout (e.g., remove ineligible items, update claims), or abandon the attempt.

For example, the Platform claims a store card benefit via context.eligibility. The Business applies member pricing during the session. At completion, the payment credential does not match the claimed instrument:

{
  "ucp": { "version": "2026-01-11", "status": "success" },
  "id": "checkout_abc",
  "status": "ready_for_complete",
  "line_items": [ "..." ],
  "totals": [ "..." ],
  "messages": [
    {
      "type": "error",
      "code": "eligibility_invalid",
      "severity": "recoverable",
      "content": "Payment credential does not match the claimed store card benefit.",
      "path": "$.context.eligibility[0]"
    }
  ]
}

The Platform can resolve this by having the buyer switch to the qualifying payment instrument, or by removing the claim from context.eligibility to renegotiate the checkout (obtaining updated pricing, availability, etc.) and then resubmitting for completion.

Warning Presentation¶

The presentation field on warning messages controls the rendering contract the platform MUST follow. When omitted, it defaults to "notice".

	`notice` (default)	`disclosure`
Display content	MUST	MUST
Proximity to `path`	MAY	MUST
Dismissible	MAY	MUST NOT
Render `image_url`	MAY	MUST
Render `url`	MAY	SHOULD
Escalate if cannot honor	—	MUST via `continue_url`

`notice` (default)¶

The default rendering contract for warnings. Platforms MUST display the warning content to the buyer. Platforms MAY render notices in a banner, tray, or toast, and MAY allow the buyer to dismiss them.

`disclosure`¶

Warnings with presentation: "disclosure" carry notices — safety warnings, allergen declarations, compliance content, etc. — that MUST follow the prescribed rendering contract below.

Platform requirements:

MUST display the warning content to the buyer.
MUST display the warning in proximity to the component referenced by path, preserving the association between the disclosure and its subject. When path is omitted, the disclosure applies to the response as a whole.
MUST NOT hide, collapse, or auto-dismiss the warning.
MUST render image_url when present (e.g., warning symbol, energy class label).
SHOULD render url as a navigable reference link when present.

Warnings with presentation: "disclosure" SHOULD be given rendering priority over notices.

Platforms that cannot honor the disclosure rendering contract MUST escalate to merchant UI via continue_url rather than silently downgrading to a notice.

Business requirements:

MUST set presentation: "disclosure" when the warning content must be displayed alongside a specific component and must not be hidden or auto-dismissed.
SHOULD use the path field to associate disclosures with the relevant component in the response.
SHOULD provide a code that identifies the disclosure category (e.g., prop65, allergens, energy_label).
SHOULD provide image_url when the disclosure has an associated visual element (e.g., warning symbol, energy class label).
SHOULD provide url when a reference link is available for the buyer to learn more.

Disclosure and Acknowledgment¶

The presentation field controls how the warning is rendered, not whether the checkout can proceed. When affirmative buyer acknowledgment or authorization is also required, the business MAY combine the disclosure with the escalation mechanisms described in the Checkout Status Lifecycle to ensure the appropriate buyer input is obtained.

Jurisdiction and Applicability¶

It is the business's responsibility to determine which disclosures apply to a given session and return only those that are relevant. Businesses SHOULD use buyer-provided data (context and other inputs) and product attributes to resolve jurisdiction-specific requirements. Platforms do not affect or resolve disclosure applicability — they render what they receive from the business.

Example¶

A checkout response containing both a recoverable error and a disclosure warning on a line item:

{
  "ucp": { "version": "2026-04-08", "status": "success" },
  "id": "chk_abc123",
  "status": "incomplete",
  "currency": "USD",
  "line_items": [
    {
      "id": "li_1",
      "item": { "id": "item_456", "title": "Artisan Nut Butter Collection", "image_url": "https://merchant.com/nut-butter.jpg" },
      "quantity": 1,
      "totals": [{ "type": "subtotal", "amount": 1299 }]
    }
  ],
  "totals": [{ "type": "total", "amount": 1299 }],
  "messages": [
    {
      "type": "error",
      "code": "field_required",
      "path": "$.buyer.email",
      "content": "Buyer email is required",
      "severity": "recoverable"
    },
    {
      "type": "warning",
      "code": "allergens",
      "path": "$.line_items[0]",
      "content": "**Contains: tree nuts.** Produced in a facility that also processes peanuts, milk, and soy.",
      "content_type": "markdown",
      "presentation": "disclosure",
      "image_url": "https://merchant.com/allergen-tree-nuts.svg",
      "url": "https://merchant.com/allergen-info"
    }
  ],
  "links": []
}

The platform resolves the recoverable error programmatically while rendering the allergen disclosure in proximity to the referenced line item.

Continue URL¶

The continue_url field enables checkout handoff from platform to business UI, allowing the buyer to continue and finalize the checkout session.

Availability¶

Businesses MUST provide continue_url when returning status = requires_escalation. For all other non-terminal statuses (incomplete, ready_for_complete, complete_in_progress), businesses SHOULD provide continue_url. For terminal states (completed, canceled), continue_url SHOULD be omitted.

Format¶

The continue_url MUST be an absolute HTTPS URL and SHOULD preserve checkout state for seamless handoff. Businesses MAY implement state preservation using either approach:

Server-Side State (Recommended)¶

An opaque URL backed by server-side checkout state:

https://business.example.com/checkout-sessions/{checkout_id}

Server maintains checkout state tied to checkout_id
Simple, secure, recommended for most implementations
URL lifetime typically tied to expires_at

Checkout Permalink¶

A stateless URL that encodes checkout state directly, allowing reconstruction without server-side persistence. Businesses SHOULD implement support for this format to facilitate checkout handoff and accelerated entry—for example, a platform can prefill checkout state when initiating a buy-now flow.

Note: Checkout permalinks are a REST-specific construct that extends the REST transport binding. Accessing a permalink returns a redirect to the checkout UI or renders the checkout page directly.

Guidelines¶

(In addition to the overarching guidelines)

Platform¶

MAY engage an agent to facilitate the checkout session (e.g. add items to the checkout session, select fulfillment address). However, the agent must hand over the checkout session to a trusted and deterministic UI for the user to review the checkout details and place the order.
MAY send the user from the trusted, deterministic UI back to the agent at any time. For example, when the user decides to exit the checkout screen to keep adding items to the cart.
MAY provide agent context when the platform indicates that the request was done by an agent.
MUST use continue_url when checkout status is requires_escalation.
MAY use continue_url to hand off to business UI in other situations.
When performing handoff, SHOULD prefer business-provided continue_url over platform-constructed checkout permalinks.

Business¶

MUST send a confirmation email after the checkout has been completed.
SHOULD provide accurate error messages.
Logic handling the checkout sessions MUST be deterministic.
MUST provide continue_url when returning status = requires_escalation.
MUST include at least one message with severity of requires_buyer_input or requires_buyer_review when returning status = requires_escalation.
SHOULD provide continue_url in all non-terminal checkout responses.
After a checkout session reaches the state "completed", it is considered immutable.

Capability Schema Definition ¶

Name	Type	Required	Description
ucp	any	Yes	UCP metadata for checkout responses.
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Response]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
context	Context	No	Provisional buyer signals for relevance and localization—not authoritative data. Businesses SHOULD use these values when verified inputs (e.g., shipping address) are absent, and MAY ignore or down-rank them if inconsistent with higher-confidence signals (authenticated account, risk detection) or regulatory constraints (export controls). Eligibility and policy enforcement MUST occur at checkout time using binding transaction data. Context SHOULD be non-identifying and can be disclosed progressively—coarse signals early, finer resolution as the session progresses. Higher-resolution data (shipping address, billing address) supersedes context.
signals	Signals	No	Environment data provided by the platform to support authorization and abuse prevention. Values MUST NOT be buyer-asserted claims — platforms provide signals based on direct observation or independently verifiable third-party attestations. All signal keys MUST use reverse-domain naming to ensure provenance and prevent collisions when multiple extensions contribute to the shared namespace.
status	string	Yes	Checkout state indicating the current phase and required action. See Checkout Status lifecycle documentation for state transition details. Enum: `incomplete`, `requires_escalation`, `ready_for_complete`, `complete_in_progress`, `completed`, `canceled`
currency	string	Yes	ISO 4217 currency code reflecting the merchant's market determination. Derived from address, context, and geo IP—buyers provide signals, merchants determine currency.
totals	Totals	Yes	Different cart totals.
messages	Array[Message]	No	List of messages with error and info about the checkout session state.
links	Array[Link]	Yes	Links to be displayed by the platform (Privacy Policy, TOS). Mandatory for legal compliance.
expires_at	string	No	RFC 3339 expiry timestamp. Default TTL is 6 hours from creation if not sent.
continue_url	string	No	URL for checkout handoff and session recovery. MUST be provided when status is requires_escalation. See specification for format and availability requirements.
payment	Payment	No	Payment configuration containing handlers.
order	Order Confirmation	No	Details about an order created for this checkout session.

Operations¶

The Checkout capability defines the following logical operations.

Operation	Description
Create Checkout	Initiates a new checkout session. Called as soon as a user adds an item to a cart.
Get Checkout	Retrieves the current state of a checkout session.
Update Checkout	Updates a checkout session.
Complete Checkout	Finalizes the checkout and places the order.
Cancel Checkout	Cancels a checkout session.

Create Checkout¶

To be invoked by the platform when the user has expressed purchase intent (e.g., click on Buy) to initiate the checkout session with the item details.

Recommendation: To minimize discrepancies and a streamlined user experience, product data (price/title etc.) provided by the business through the feeds SHOULD match the actual attributes returned in the response.

Inputs

Name	Type	Required	Description
line_items	Array[Line Item]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
context	Context	No	Provisional buyer signals for relevance and localization—not authoritative data. Businesses SHOULD use these values when verified inputs (e.g., shipping address) are absent, and MAY ignore or down-rank them if inconsistent with higher-confidence signals (authenticated account, risk detection) or regulatory constraints (export controls). Eligibility and policy enforcement MUST occur at checkout time using binding transaction data. Context SHOULD be non-identifying and can be disclosed progressively—coarse signals early, finer resolution as the session progresses. Higher-resolution data (shipping address, billing address) supersedes context.
signals	Signals	No	Environment data provided by the platform to support authorization and abuse prevention. Values MUST NOT be buyer-asserted claims — platforms provide signals based on direct observation or independently verifiable third-party attestations. All signal keys MUST use reverse-domain naming to ensure provenance and prevent collisions when multiple extensions contribute to the shared namespace.
payment	Payment	No	Payment configuration containing handlers.

Output

This object MUST be one of the following types: Checkout, Error Response.

Get Checkout¶

It provides the latest state of the checkout resource. After cancellation or completion it is up to the business on what to return (i.e this can be a long lived state or expire after a particular TTL - resulting in a 'not found' error). From the platform there is no specific enforcement for a TTL of the checkout.

The platform will honor the TTL provided by the business via expires_at at the time of checkout session creation.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.

Output

This object MUST be one of the following types: Checkout, Error Response.

Update Checkout¶

Performs a full replacement of the checkout resource. The platform is REQUIRED to send the entire checkout resource containing any data updates to write-only data fields. The resource provided in the request will replace the existing checkout session state on the business side.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.
line_items	Array[Line Item]	No	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
context	Context	No	Provisional buyer signals for relevance and localization—not authoritative data. Businesses SHOULD use these values when verified inputs (e.g., shipping address) are absent, and MAY ignore or down-rank them if inconsistent with higher-confidence signals (authenticated account, risk detection) or regulatory constraints (export controls). Eligibility and policy enforcement MUST occur at checkout time using binding transaction data. Context SHOULD be non-identifying and can be disclosed progressively—coarse signals early, finer resolution as the session progresses. Higher-resolution data (shipping address, billing address) supersedes context.
signals	Signals	No	Environment data provided by the platform to support authorization and abuse prevention. Values MUST NOT be buyer-asserted claims — platforms provide signals based on direct observation or independently verifiable third-party attestations. All signal keys MUST use reverse-domain naming to ensure provenance and prevent collisions when multiple extensions contribute to the shared namespace.
payment	Payment	No	Payment configuration containing handlers.

Output

This object MUST be one of the following types: Checkout, Error Response.

Complete Checkout¶

This is the final checkout placement call. To be invoked when the user has committed to pay and place an order for the chosen items. The response of this call is the checkout object with the order field populated in it. The returned order provides necessary identifiers, such as id and permalink_url, that can be used to reference the full state of the placed order. At the time of order persistence, fields from Checkout MAY be used to construct the order representation (i.e. information like line_items, fulfillment will be used to create the initial order representation).

After this call, other details will be updated through subsequent events as the order, and its associated items, moves through the supply chain.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.
signals	Signals	No	Environment data provided by the platform to support authorization and abuse prevention. Values MUST NOT be buyer-asserted claims — platforms provide signals based on direct observation or independently verifiable third-party attestations. All signal keys MUST use reverse-domain naming to ensure provenance and prevent collisions when multiple extensions contribute to the shared namespace.
payment	Payment	No	Payment configuration containing handlers.

Output

This object MUST be one of the following types: Checkout, Error Response.

Cancel Checkout¶

This operation will be used to cancel a checkout session, if it can be canceled. If the checkout session cannot be canceled (e.g. checkout session is already canceled or completed), then businesses SHOULD send back an error indicating the operation is not allowed. Any checkout session with a status that is not equal to completed or canceled SHOULD be cancelable.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.

Output

This object MUST be one of the following types: Checkout, Error Response.

Transport Bindings¶

The abstract operations above are bound to specific transport protocols as defined below:

REST Binding: RESTful API mapping using standard HTTP verbs and JSON payloads.
MCP Binding: Model Context Protocol mapping for agentic interaction.
A2A Binding: Agent-to-Agent Protocol mapping for agentic interactions.
Embedded Checkout Binding: JSON-RPC for powering embedded checkout.

Entities¶

Buyer¶

Name	Type	Required	Description
first_name	string	No	First name of the buyer.
last_name	string	No	Last name of the buyer.
email	string	No	Email of the buyer.
phone_number	string	No	E.164 standard.

Context¶

Context signals are provisional—not authoritative data. Businesses SHOULD use these values when verified inputs (e.g., shipping address) are absent, and MAY ignore or down-rank them if inconsistent with higher-confidence signals (authenticated account, risk detection) or regulatory constraints (export controls). Eligibility and policy enforcement MUST occur at checkout time using binding transaction data.

Name	Type	Required	Description
address_country	string	No	The country. Recommended to be in 2-letter ISO 3166-1 alpha-2 format, for example "US". For backward compatibility, a 3-letter ISO 3166-1 alpha-3 country code such as "SGP" or a full country name such as "Singapore" can also be used. Optional hint for market context (currency, availability, pricing)—higher-resolution data (e.g., shipping address) supersedes this value.
address_region	string	No	The region in which the locality is, and which is in the country. For example, California or another appropriate first-level Administrative division. Optional hint for progressive localization—higher-resolution data (e.g., shipping address) supersedes this value.
postal_code	string	No	The postal code. For example, 94043. Optional hint for regional refinement—higher-resolution data (e.g., shipping address) supersedes this value.
intent	string	No	Background context describing buyer's intent (e.g., 'looking for a gift under $50', 'need something durable for outdoor use'). Informs relevance, recommendations, and personalization.
language	string	No	Preferred language for content. Use IETF BCP 47 language tags (e.g., 'en', 'fr-CA', 'zh-Hans'). For REST, equivalent to Accept-Language header—platforms SHOULD fall back to Accept-Language when this field is absent; when provided, overrides Accept-Language. Businesses MAY return content in a different language if unavailable.
currency	string	No	Preferred currency (ISO 4217, e.g., 'EUR', 'USD'). Businesses determine presentment currency from context and authoritative signals; this hint MAY inform selection in multi-currency markets. Also serves as the denomination for price filter values — platforms SHOULD include this field when sending price filters. Response prices include explicit currency confirming the resolution.
eligibility	Array[Reverse Domain Name]	No	Buyer claims about eligible benefits such as loyalty membership, payment instrument perks, and similar. Recognized claims MAY inform the Business response (e.g., member-only product availability, adjusted pricing in catalog, provisional discounts at cart or checkout). Businesses MUST ignore unrecognized values without error. Values MUST use reverse-domain naming (e.g., 'com.example.loyalty_gold', 'org.school.student') and MUST be non-identifying.

Signals¶

Environment data provided by the platform to support authorization and abuse prevention. Unlike context (buyer-asserted preferences) and buyer (self-reported identity), signal values MUST NOT be buyer-asserted claims — platforms provide signals based on direct observation or by relaying independently verifiable third-party attestations. See Signals for details and privacy requirements.

Name	Type	Required	Description
dev.ucp.buyer_ip	string	No	Client's IP address (IPv4 or IPv6).
dev.ucp.user_agent	string	No	Client's HTTP User-Agent header or equivalent.

Fulfillment Option¶

A fulfillment option within a group (e.g., Standard Shipping $5, Express $15).

Name	Type	Required	Description
id	string	Yes	Unique fulfillment option identifier.
title	string	Yes	Short label (e.g., 'Express Shipping', 'Curbside Pickup').
description	string	No	Complete context for buyer decision (e.g., 'Arrives Dec 12-15 via FedEx').
carrier	string	No	Carrier name (for shipping).
earliest_fulfillment_time	string	No	Earliest fulfillment date.
latest_fulfillment_time	string	No	Latest fulfillment date.
totals	Array[object]	Yes	Fulfillment option totals breakdown.

Item¶

Item Create Request¶

Name	Type	Required	Description
id	string	Yes	The product identifier, often the SKU, required to resolve the product details associated with this line item. Should be recognized by both the Platform, and the Business.

Item Update Request¶

Name	Type	Required	Description
id	string	Yes	The product identifier, often the SKU, required to resolve the product details associated with this line item. Should be recognized by both the Platform, and the Business.

Item¶

Name	Type	Required	Description
id	string	Yes	The product identifier, often the SKU, required to resolve the product details associated with this line item. Should be recognized by both the Platform, and the Business.
title	string	Yes	Product title.
price	Amount	Yes	Unit price in ISO 4217 minor units.
image_url	string	No	Product image URI.

Line Item¶

Line Item Create Request¶

Name	Type	Required	Description
item	Item	Yes
quantity	integer	Yes	Quantity of the item being purchased.

Line Item Update Request¶

Name	Type	Required	Description
id	string	No
item	Item	Yes
quantity	integer	Yes	Quantity of the item being purchased.
parent_id	string	No	Parent line item identifier for any nested structures.

Line Item¶

Name	Type	Required	Description
id	string	Yes
item	Item	Yes
quantity	integer	Yes	Quantity of the item being purchased.
totals	Array[Total]	Yes	Line item totals breakdown.
parent_id	string	No	Parent line item identifier for any nested structures.

Link¶

Name	Type	Required	Description
type	string	Yes	Type of link. Well-known values: `privacy_policy`, `terms_of_service`, `refund_policy`, `shipping_policy`, `faq`. Consumers SHOULD handle unknown values gracefully by displaying them using the `title` field or omitting the link.
url	string	Yes	The actual URL pointing to the content to be displayed.
title	string	No	Optional display text for the link. When provided, use this instead of generating from type.

Well-Known Link Types¶

Businesses SHOULD provide all relevant links for the transaction. The following are the recommended well-known types:

Type	Description
`privacy_policy`	Link to the business's privacy policy
`terms_of_service`	Link to the business's terms of service
`refund_policy`	Link to the business's refund policy
`shipping_policy`	Link to the business's shipping policy
`faq`	Link to the business's frequently asked questions

Businesses MAY define custom types for domain-specific needs. Platforms SHOULD handle unknown types gracefully by displaying them using the title field or omitting them.

Message¶

This object MUST be one of the following types: Message Error, Message Warning, Message Info.

Message Error¶

Name	Type	Required	Description
type	string	Yes	Constant = error. Message type discriminator.
code	Error Code	Yes	Error code identifying the type of error. Standard errors are defined in specification (see examples), and have standardized semantics; freeform codes are permitted.
path	string	No	RFC 9535 JSONPath to the component the message refers to (e.g., $.items[1]).
content_type	string	No	Content format, default = plain. Enum: `plain`, `markdown`
content	string	Yes	Human-readable message.
severity	string	Yes	Reflects the resource state and recommended action. 'recoverable': platform can resolve by modifying inputs and retrying via API. 'requires_buyer_input': merchant requires information their API doesn't support collecting programmatically (checkout incomplete). 'requires_buyer_review': buyer must authorize before order placement due to policy, regulatory, or entitlement rules. 'unrecoverable': no valid resource exists to act on, retry with new resource or inputs. Errors with 'requires_' severity contribute to 'status: requires_escalation'. Enum:* `recoverable`, `requires_buyer_input`, `requires_buyer_review`, `unrecoverable`

Error Code¶

Error code identifying the type of error. Standard errors are defined in specification (see examples), and have standardized semantics; freeform codes are permitted.

Message Info¶

Name	Type	Required	Description
type	string	Yes	Constant = info. Message type discriminator.
path	string	No	RFC 9535 JSONPath to the component the message refers to.
code	string	No	Info code for programmatic handling.
content_type	string	No	Content format, default = plain. Enum: `plain`, `markdown`
content	string	Yes	Human-readable message.

Message Warning¶

Name	Type	Required	Description
type	string	Yes	Constant = warning. Message type discriminator.
path	string	No	JSONPath (RFC 9535) to related field (e.g., $.line_items[0]).
code	string	Yes	Warning code. Machine-readable identifier for the warning type (e.g., final_sale, prop65, fulfillment_changed, age_restricted, etc.).
content	string	Yes	Human-readable warning message that MUST be displayed.
content_type	string	No	Content format, default = plain. Enum: `plain`, `markdown`
presentation	string	No	Rendering contract for this warning. 'notice' (default): platform MUST display, MAY dismiss. 'disclosure': platform MUST display in proximity to the path-referenced component, MUST NOT hide or auto-dismiss. See specification for full contract.
image_url	string	No	URL to a required visual element (e.g., warning symbol, energy class label).
url	string	No	Reference URL for more information (e.g., regulatory site, registry entry, policy page).

Payment¶

Name	Type	Required	Description
instruments	Array[Payment Instrument Selected Payment Instrument]	No	The payment instruments available for this payment. Each instrument is associated with a specific handler via the handler_id field. Handlers can extend the base payment_instrument schema to add handler-specific fields.

Selected Payment Instrument¶

A payment instrument with selection state.

Name	Type	Required	Description
id	string	Yes	A unique identifier for this instrument instance, assigned by the platform.
handler_id	string	Yes	The unique identifier for the handler instance that produced this instrument. This corresponds to the 'id' field in the Payment Handler definition.
type	string	Yes	The broad category of the instrument (e.g., 'card', 'tokenized_card'). Specific schemas will constrain this to a constant value.
billing_address	object	No	The billing address associated with this payment method.
credential	object	No	The base definition for any payment credential. Handlers define specific credential types.
display	object	No	Display information for this payment instrument. Each payment instrument schema defines its specific display properties, as outlined by the payment handler.
selected	boolean	No	Whether this instrument is selected by the user.

Payment Credential¶

Name	Type	Required	Description
type	string	Yes	The credential type discriminator. Specific schemas will constrain this to a constant value.

Postal Address¶

Name	Type	Required	Description
extended_address	string	No	An address extension such as an apartment number, C/O or alternative name.
street_address	string	No	The street address.
address_locality	string	No	The locality in which the street address is, and which is in the region. For example, Mountain View.
address_region	string	No	The region in which the locality is, and which is in the country. Required for applicable countries (i.e. state in US, province in CA). For example, California or another appropriate first-level Administrative division.
address_country	string	No	The country. Recommended to be in 2-letter ISO 3166-1 alpha-2 format, for example "US". For backward compatibility, a 3-letter ISO 3166-1 alpha-3 country code such as "SGP" or a full country name such as "Singapore" can also be used.
postal_code	string	No	The postal code. For example, 94043.
first_name	string	No	Optional. First name of the contact associated with the address.
last_name	string	No	Optional. Last name of the contact associated with the address.
phone_number	string	No	Optional. Phone number of the contact associated with the address.

Response¶

Capability reference in responses. Only name/version required to confirm active capabilities.

Name	Type	Required	Description
version	string	Yes	Entity version in YYYY-MM-DD format.
spec	string	No	URL to human-readable specification document.
schema	string	No	URL to JSON Schema defining this entity's structure and payloads.
id	string	No	Unique identifier for this entity instance. Used to disambiguate when multiple instances exist.
config	object	No	Entity-specific configuration. Structure defined by each entity's schema.
extends	OneOf[]	No	Parent capability(s) this extends. Present for extensions, absent for root capabilities. Use array for multi-parent extensions.

Total¶

Name	Type	Required	Description

Rendering Contract¶

Businesses are the authoritative source for presented totals — their content and order — because the correct presentation is subject to regional, product, and regulatory requirements that the business is obligated to satisfy (e.g., multi-jurisdiction tax itemization, mandatory fee disclosures).

Platforms MUST render all top-level entries in the order provided:

for entry in totals:
    render_line(entry.display_text, entry.amount)

Platforms MAY render sub-lines as supplementary detail:

for entry in totals:
    render_line(entry.display_text, entry.amount)
    if entry.lines:
        for sub in entry.lines:
            render_detail_line(sub.display_text, sub.amount)

Platforms MUST NOT interpret, filter, reorder, aggregate, or apply display logic of their own.

Invariants of totals[]:

Every entry carries a type and an amount. Platforms SHOULD use display_text when provided. Well-known types have default display labels as fallback (see table below); unknown types MUST include display_text.
Amounts are signed integers — negative values are subtractive (e.g., discounts), positive values are additive. The sign IS the direction.
Exactly one type: "subtotal" MUST be present.
Exactly one type: "total" MUST be present.

Verification¶

Platforms MUST NOT substitute their own computed totals for the business's values. Platforms MAY verify the provided totals:

assert sum(e.amount for e in totals if e.type != "total") == total_entry.amount

If the computed sum does not match the type: "total" entry, the platform MUST NOT alter the rendered output — the business's presented totals are authoritative for display. However, platforms MUST NOT autonomously complete a checkout with mismatched totals. Platforms SHOULD reject the checkout or escalate and ask for buyer review via continue_url.

Well-Known Types¶

Type	Sign	Default label	Meaning
`subtotal`	+	Subtotal	Sum of line item prices
`discount`	−	Discount	Order or line-item level discount
`items_discount`	−	Item Discounts	Rollup of line-item discounts
`fulfillment`	+	Shipping	Shipping, delivery, or pickup charges
`tax`	+	Tax	Tax charges
`fee`	+	Fee	Fees and surcharges
`total`	=	Total	Authoritative grand total (exactly one)

When display_text is provided, platforms MUST use it. When omitted on a well-known type, platforms SHOULD use the default label above. The sign convention for well-known types is schema-enforced: subtractive types (discount, items_discount) MUST have negative amounts; additive types (subtotal, fulfillment, tax, fee) MUST have non-negative amounts.

The type field is an open string — businesses MAY use values beyond the well-known set. Unknown types MUST include display_text (schema-enforced) and the sign on the amount is self-describing.

Repeating Types¶

All types except subtotal and total MAY appear multiple times — for example, multi-jurisdiction tax lines or itemized fees.

Sub-Lines (`lines`)¶

Each top-level entry MAY include a lines array. Sub-lines share the same base shape as top-level entries — display_text and amount — providing an itemized breakdown under the parent.

Invariant: sum(lines[].amount) MUST equal the parent entry's amount.

The business controls what MUST be rendered (top-level entries) versus what MAY be optionally surfaced (sub-lines). Platforms SHOULD render sub-lines when provided.

Examples¶

Split tax, itemized at top-level:

"totals": [
  { "type": "subtotal",    "display_text": "Subtotal",    "amount": 5750 },
  { "type": "fulfillment", "display_text": "Shipping",    "amount": 899 },
  { "type": "tax",         "display_text": "Federal Tax", "amount": 332 },
  { "type": "tax",         "display_text": "State Tax",   "amount": 465 },
  { "type": "total",       "display_text": "Total",       "amount": 7446 }
]

Collapsed fees with optional breakdown:

"totals": [
  { "type": "subtotal", "display_text": "Subtotal", "amount": 4999 },
  {
    "type": "fee", "display_text": "Fees", "amount": 549,
    "lines": [
      { "display_text": "Service Fee", "amount": 399 },
      { "display_text": "Recycling Fee", "amount": 150 }
    ]
  },
  { "type": "tax",   "display_text": "Tax",   "amount": 444 },
  { "type": "total", "display_text": "Total", "amount": 5992 }
]

Discount and account credit — negative amounts:

"totals": [
  { "type": "subtotal",       "display_text": "Subtotal",       "amount": 10000 },
  { "type": "discount",       "display_text": "Summer Sale",    "amount": -1500 },
  { "type": "tax",            "display_text": "Tax",            "amount": 680 },
  { "type": "account_credit", "display_text": "Account Credit", "amount": -2500 },
  { "type": "total",          "display_text": "Amount Due",     "amount": 6680 }
]

UCP Response Checkout¶

UCP metadata for checkout responses.

Name	Type	Required	Description
version	string	Yes	UCP version in YYYY-MM-DD format.
status	string	No	Application-level status of the UCP operation. Enum: `success`, `error`
services	object	No	Service registry keyed by reverse-domain name.
capabilities	object	No	Capability registry keyed by reverse-domain name.
payment_handlers	object	Yes	Payment handler registry keyed by reverse-domain name.
services	any	No
capabilities	any	No
payment_handlers	any	Yes

Order Confirmation¶

Name	Type	Required	Description
id	string	Yes	Unique order identifier.
label	string	No	Human-readable label for identifying the order. MUST only be provided by the business.
permalink_url	string	Yes	Permalink to access the order on merchant site.

Error Response ¶

Name	Type	Required	Description
ucp	any	Yes	UCP protocol metadata. Status MUST be 'error' for error response.
messages	Array[Message]	Yes	Array of messages describing why the operation failed.
continue_url	string	No	URL for buyer handoff or session recovery.

Checkout Capability¶

Overview¶

Flow overview¶

Payments¶

Fulfillment¶

Checkout Status Lifecycle¶

Status Values¶

Error Handling¶

Error Processing Algorithm¶

Standard Errors¶

Eligibility Verification at Completion¶

Warning Presentation¶

notice (default)¶

disclosure¶

Disclosure and Acknowledgment¶

Jurisdiction and Applicability¶

Example¶

Continue URL¶

Availability¶

Format¶

Server-Side State (Recommended)¶

Checkout Permalink¶

Guidelines¶

Platform¶

Business¶

Capability Schema Definition ¶

Operations¶

Create Checkout¶

Get Checkout¶

Update Checkout¶

Complete Checkout¶

Cancel Checkout¶

Transport Bindings¶

Entities¶

Buyer¶

Context¶

Signals¶

Fulfillment Option¶

Item¶

Item Create Request¶

Item Update Request¶

Item¶

Line Item¶

Line Item Create Request¶

Line Item Update Request¶

Line Item¶

Link¶

Well-Known Link Types¶

Message¶

Message Error¶

Error Code¶

Message Info¶

Message Warning¶

Payment¶

Selected Payment Instrument¶

Payment Credential¶

Postal Address¶

Response¶

Total¶

Rendering Contract¶

Verification¶

Well-Known Types¶

Repeating Types¶

Sub-Lines (lines)¶

Examples¶

UCP Response Checkout¶

Order Confirmation¶

Error Response ¶

`notice` (default)¶

`disclosure`¶

Sub-Lines (`lines`)¶
