Checkout Capability¶

Capability Name: dev.ucp.shopping.checkout
Version: 2026-01-11

Overview¶

Allows platforms to facilitate checkout sessions. The checkout has to be finalized manually by the user through a trusted UI unless the AP2 Mandates extension is supported.

The business remains the Merchant of Record (MoR), and they don't need to become PCI DSS compliant to support this Capability.

Flow overview

High-level checkout flow sequence diagram

Payments

On checkout creation, businesses are required to define a payment configuration. The Checkout object includes payment.handlers which define the processing specifications for collecting payment instruments (e.g., Google Pay, direct tokenization). When the buyer submits payment, the platform populates the payment.instruments array with the collected instrument data.

Fulfillment

Fulfillment is modelled as an extension in UCP to account for diverse use cases.

Fulfillment is optional in the checkout object. This is done to enable a platform to perform checkout for digital goods without needing to furnish fulfillment details more relevant for physical goods.

Checkout Status Lifecycle

The checkout status field indicates the current phase of the session and determines what action is required next. The business sets the status; the platform receives messages indicating what's needed to progress.

┌────────────┐    ┌─────────────────────┐
│ incomplete │◀──▶│ requires_escalation │
└─────┬──────┘    │                     │
      │           │  (buyer handoff     │
      │           │   via continue_url) │
      │           └──────────┬──────────┘
      │                      │
      │ all info collected   │ continue_url
      ▼                      │
┌──────────────────┐         │
│ready_for_complete│         │
│                  │         │
│ (platform can    │         │
│ call Complete    │         │
│   Checkout).     │         │
└────────┬─────────┘         │
         │                   │
         │ Complete Checkout │
         ▼                   │
┌────────────────────┐       │
│complete_in_progress│       │
└─────────┬──────────┘       │
          │                  │
          └────────┬─────────┘
                   ▼
            ┌─────────────┐
            │  completed  │
            └─────────────┘

            ┌─────────────┐
            │  canceled   │  (session invalid/expired - can occur from any state)
            └─────────────┘

Status Values

incomplete: Checkout session is missing required information or has issues that need resolution. Platform should inspect messages array for context and should attempt to resolve via Update Checkout.
requires_escalation: Checkout session requires information that cannot be provided via API, or buyer input is required. Platform should inspect messages to understand what's needed (see Error Handling below). If any recoverable errors exist, resolve those first. Then hand off to buyer via continue_url.
ready_for_complete: Checkout session has all necessary information and platform can finalize programmatically. Platform can call Complete Checkout.
complete_in_progress: Business is processing the Complete Checkout request.
completed: Order placed successfully.
canceled: Checkout session is invalid or expired. Platform should start a new checkout session if needed.

Error Handling¶

The messages array contains errors, warnings, and informational messages about the checkout state. Error messages include a severity field that declares who resolves the error:

Severity	Meaning	Platform Action
`recoverable`	Platform can fix via API	Resolve using Update Checkout
`requires_buyer_input`	Business requires input not available via API	Hand off via `continue_url`
`requires_buyer_review`	Buyer review and authorization is required	Hand off via `continue_url`

Errors with requires_* severity contribute to status: requires_escalation. Both result in buyer handoff, but represent different checkout states.

requires_buyer_input means the checkout is incomplete — the business requires information their API doesn't support collecting programmatically.
requires_buyer_review means the checkout is complete — but policy, regulatory, or entitlement rules require buyer authorization before order placement (e.g., high-value order approval, first-purchase policy).

Error Processing Algorithm¶

When status is incomplete or requires_escalation, platforms should process errors as a prioritized stack. The example below illustrates a checkout with three error types: a recoverable error (invalid phone), a buyer input requirement (delivery scheduling), and a review requirement (high-value order). The latter two require handoff and serve as explicit signals to the platform. Businesses SHOULD surface such messages as early as possible, and platforms SHOULD prioritize resolving recoverable errors before initiating handoff.

{
  "status": "requires_escalation",
  "messages": [
    {
      "type": "error",
      "code": "invalid_phone",
      "severity": "recoverable",
      "content": "Phone number format is invalid"
    },
    {
      "type": "error",
      "code": "schedule_delivery",
      "severity": "requires_buyer_input",
      "content": "Select delivery window for your purchase"
    },
    {
      "type": "error",
      "code": "high_value_order",
      "severity": "requires_buyer_review",
      "content": "Orders over $500 require additional verification"
    }
  ]
}

Example error processing algorithm:

GIVEN checkout with messages array
FILTER errors FROM messages WHERE type = "error"

PARTITION errors INTO
  recoverable           WHERE severity = "recoverable"
  requires_buyer_input  WHERE severity = "requires_buyer_input"
  requires_buyer_review WHERE severity = "requires_buyer_review"

IF recoverable is not empty
  FOR EACH error IN recoverable
    ATTEMPT to fix error (e.g., reformat phone number)
  CALL Update Checkout
  RETURN and re-evaluate response

IF requires_buyer_input is not empty
  handoff_context = "incomplete, additional input from buyer is required"
ELSE IF requires_buyer_review is not empty
  handoff_context = "ready for final review by the buyer"

Continue URL¶

The continue_url field enables checkout handoff from platform to business UI, allowing the buyer to continue and finalize the checkout session.

Availability¶

Businesses MUST provide continue_url when returning status = requires_escalation. For all other non-terminal statuses (incomplete, ready_for_complete, complete_in_progress), businesses SHOULD provide continue_url. For terminal states (completed, canceled), continue_url SHOULD be omitted.

Format¶

The continue_url MUST be an absolute HTTPS URL and SHOULD preserve checkout state for seamless handoff. Businesses MAY implement state preservation using either approach:

Server-Side State (Recommended)¶

An opaque URL backed by server-side checkout state:

https://business.example.com/checkout-sessions/{checkout_id}

Server maintains checkout state tied to checkout_id
Simple, secure, recommended for most implementations
URL lifetime typically tied to expires_at

Checkout Permalink¶

A stateless URL that encodes checkout state directly, allowing reconstruction without server-side persistence. Businesses SHOULD implement support for this format to facilitate checkout handoff and accelerated entry—for example, a platform can prefill checkout state when initiating a buy-now flow.

Note: Checkout permalinks are a REST-specific construct that extends the REST transport binding. Accessing a permalink returns a redirect to the checkout UI or renders the checkout page directly.

Guidelines¶

(In addition to the overarching guidelines)

Platform

MAY engage an agent to facilitate the checkout session (e.g. add items to the checkout session, select fulfillment address). However, the agent must hand over the checkout session to a trusted and deterministic UI for the user to review the checkout details and place the order.
MAY send the user from the trusted, deterministic UI back to the agent at any time. For example, when the user decides to exit the checkout screen to keep adding items to the cart.
MAY provide agent context when the platform indicates that the request was done by an agent.
MUST use continue_url when checkout status is requires_escalation.
MAY use continue_url to hand off to business UI in other situations.
When performing handoff, SHOULD prefer business-provided continue_url over platform-constructed checkout permalinks.

Business

MUST send a confirmation email after the checkout has been completed.
SHOULD provide accurate error messages.
Logic handling the checkout sessions MUST be deterministic.
MUST provide continue_url when returning status = requires_escalation.
MUST include at least one message with severity: escalation when returning status = requires_escalation.
SHOULD provide continue_url in all non-terminal checkout responses.
After a checkout session reaches the state "completed", it is considered immutable.

Capability Schema Definition¶

Name	Type	Required	Description
ucp	UCP Response Checkout	Yes
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Response]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
status	string	Yes	Checkout state indicating the current phase and required action. See Checkout Status lifecycle documentation for state transition details. Enum: `incomplete`, `requires_escalation`, `ready_for_complete`, `complete_in_progress`, `completed`, `canceled`
currency	string	Yes	ISO 4217 currency code.
totals	Array[Total Response]	Yes	Different cart totals.
messages	Array[Message]	No	List of messages with error and info about the checkout session state.
links	Array[Link]	Yes	Links to be displayed by the platform (Privacy Policy, TOS). Mandatory for legal compliance.
expires_at	string	No	RFC 3339 expiry timestamp. Default TTL is 6 hours from creation if not sent.
continue_url	string	No	URL for checkout handoff and session recovery. MUST be provided when status is requires_escalation. See specification for format and availability requirements.
payment	Payment Response	Yes
order	Order Confirmation	No	Details about an order created for this checkout session.

Operations¶

The Checkout capability defines the following logical operations.

Operation	Description
Create Checkout	Initiates a new checkout session. Called as soon as a user adds an item to a cart.
Get Checkout	Retrieves the current state of a checkout session.
Update Checkout	Updates a checkout session.
Complete Checkout	Finalizes the checkout and places the order.
Cancel Checkout	Cancels a checkout session.

Create Checkout¶

To be invoked by the platform when the user has expressed purchase intent (e.g., click on Buy) to initiate the checkout session with the item details.

Recommendation: To minimize discrepancies and a streamlined user experience, product data (price/title etc.) provided by the business through the feeds SHOULD match the actual attributes returned in the response.

Inputs

Name	Type	Required	Description
line_items	Array[Line Item Create Request]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
currency	string	Yes	ISO 4217 currency code.
payment	Payment Create Request	Yes

Output

Name	Type	Required	Description
ucp	UCP Response Checkout	Yes
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Response]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
status	string	Yes	Checkout state indicating the current phase and required action. See Checkout Status lifecycle documentation for state transition details. Enum: `incomplete`, `requires_escalation`, `ready_for_complete`, `complete_in_progress`, `completed`, `canceled`
currency	string	Yes	ISO 4217 currency code.
totals	Array[Total Response]	Yes	Different cart totals.
messages	Array[Message]	No	List of messages with error and info about the checkout session state.
links	Array[Link]	Yes	Links to be displayed by the platform (Privacy Policy, TOS). Mandatory for legal compliance.
expires_at	string	No	RFC 3339 expiry timestamp. Default TTL is 6 hours from creation if not sent.
continue_url	string	No	URL for checkout handoff and session recovery. MUST be provided when status is requires_escalation. See specification for format and availability requirements.
payment	Payment Response	Yes
order	Order Confirmation	No	Details about an order created for this checkout session.

Get Checkout¶

It provides the latest state of the checkout resource. After cancellation or completion it is up to the business on what to return (i.e this can be a long lived state or expire after a particular TTL - resulting in a 'not found' error). From the platform there is no specific enforcement for a TTL of the checkout.

The platform will honor the TTL provided by the business via expires_at at the time of checkout session creation.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.

Output

Name	Type	Required	Description
ucp	UCP Response Checkout	Yes
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Response]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
status	string	Yes	Checkout state indicating the current phase and required action. See Checkout Status lifecycle documentation for state transition details. Enum: `incomplete`, `requires_escalation`, `ready_for_complete`, `complete_in_progress`, `completed`, `canceled`
currency	string	Yes	ISO 4217 currency code.
totals	Array[Total Response]	Yes	Different cart totals.
messages	Array[Message]	No	List of messages with error and info about the checkout session state.
links	Array[Link]	Yes	Links to be displayed by the platform (Privacy Policy, TOS). Mandatory for legal compliance.
expires_at	string	No	RFC 3339 expiry timestamp. Default TTL is 6 hours from creation if not sent.
continue_url	string	No	URL for checkout handoff and session recovery. MUST be provided when status is requires_escalation. See specification for format and availability requirements.
payment	Payment Response	Yes
order	Order Confirmation	No	Details about an order created for this checkout session.

Update Checkout¶

Performs a full replacement of the checkout resource. The platform is REQUIRED to send the entire checkout resource containing any data updates to write-only data fields. The resource provided in the request will replace the existing checkout session state on the business side.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Update Request]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
currency	string	Yes	ISO 4217 currency code.
payment	Payment Update Request	Yes

Output

Name	Type	Required	Description
ucp	UCP Response Checkout	Yes
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Response]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
status	string	Yes	Checkout state indicating the current phase and required action. See Checkout Status lifecycle documentation for state transition details. Enum: `incomplete`, `requires_escalation`, `ready_for_complete`, `complete_in_progress`, `completed`, `canceled`
currency	string	Yes	ISO 4217 currency code.
totals	Array[Total Response]	Yes	Different cart totals.
messages	Array[Message]	No	List of messages with error and info about the checkout session state.
links	Array[Link]	Yes	Links to be displayed by the platform (Privacy Policy, TOS). Mandatory for legal compliance.
expires_at	string	No	RFC 3339 expiry timestamp. Default TTL is 6 hours from creation if not sent.
continue_url	string	No	URL for checkout handoff and session recovery. MUST be provided when status is requires_escalation. See specification for format and availability requirements.
payment	Payment Response	Yes
order	Order Confirmation	No	Details about an order created for this checkout session.

Complete Checkout¶

This is the final checkout placement call. To be invoked when the user has committed to pay and place an order for the chosen items. The response of this call is the checkout object with the order field populated in it. The returned order provides necessary identifiers, such as id and permalink_url, that can be used to reference the full state of the placed order. At the time of order persistence, fields from Checkout MAY be used to construct the order representation (i.e. information like line_items, fulfillment will be used to create the initial order representation).

After this call, other details will be updated through subsequent events as the order, and its associated items, moves through the supply chain.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.
payment_data	Payment Instrument	Yes
risk_signals	object	No	Key-value pairs of risk signals.

Output

Name	Type	Required	Description
ucp	UCP Response Checkout	Yes
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Response]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
status	string	Yes	Checkout state indicating the current phase and required action. See Checkout Status lifecycle documentation for state transition details. Enum: `incomplete`, `requires_escalation`, `ready_for_complete`, `complete_in_progress`, `completed`, `canceled`
currency	string	Yes	ISO 4217 currency code.
totals	Array[Total Response]	Yes	Different cart totals.
messages	Array[Message]	No	List of messages with error and info about the checkout session state.
links	Array[Link]	Yes	Links to be displayed by the platform (Privacy Policy, TOS). Mandatory for legal compliance.
expires_at	string	No	RFC 3339 expiry timestamp. Default TTL is 6 hours from creation if not sent.
continue_url	string	No	URL for checkout handoff and session recovery. MUST be provided when status is requires_escalation. See specification for format and availability requirements.
payment	Payment Response	Yes
order	Order Confirmation	No	Details about an order created for this checkout session.

Cancel Checkout¶

This operation will be used to cancel a checkout session, if it can be canceled. If the checkout session cannot be canceled (e.g. checkout session is already canceled or completed), then businesses SHOULD send back an error indicating the operation is not allowed. Any checkout session with a status that is not equal to completed or canceled SHOULD be cancelable.

Inputs

Name	Type	Required	Description
id	string	Yes	The unique identifier of the checkout session.Defined in path.

Output

Name	Type	Required	Description
ucp	UCP Response Checkout	Yes
id	string	Yes	Unique identifier of the checkout session.
line_items	Array[Line Item Response]	Yes	List of line items being checked out.
buyer	Buyer	No	Representation of the buyer.
status	string	Yes	Checkout state indicating the current phase and required action. See Checkout Status lifecycle documentation for state transition details. Enum: `incomplete`, `requires_escalation`, `ready_for_complete`, `complete_in_progress`, `completed`, `canceled`
currency	string	Yes	ISO 4217 currency code.
totals	Array[Total Response]	Yes	Different cart totals.
messages	Array[Message]	No	List of messages with error and info about the checkout session state.
links	Array[Link]	Yes	Links to be displayed by the platform (Privacy Policy, TOS). Mandatory for legal compliance.
expires_at	string	No	RFC 3339 expiry timestamp. Default TTL is 6 hours from creation if not sent.
continue_url	string	No	URL for checkout handoff and session recovery. MUST be provided when status is requires_escalation. See specification for format and availability requirements.
payment	Payment Response	Yes
order	Order Confirmation	No	Details about an order created for this checkout session.

Transport Bindings¶

The abstract operations above are bound to specific transport protocols as defined below:

REST Binding: RESTful API mapping using standard HTTP verbs and JSON payloads.
MCP Binding: Model Context Protocol mapping for agentic interaction.
A2A Binding: Agent-to-Agent Protocol mapping for agentic interactions.
Embedded Checkout Binding: JSON-RPC for powering embedded checkout.

Entities¶

Buyer¶

Name	Type	Required	Description
first_name	string	No	First name of the buyer.
last_name	string	No	Last name of the buyer.
full_name	string	No	Optional, buyer's full name (if first_name or last_name fields are present they take precedence).
email	string	No	Email of the buyer.
phone_number	string	No	E.164 standard.

Fulfillment Option¶

Name	Type	Required	Description
id	string	Yes	Unique fulfillment option identifier.
title	string	Yes	Short label (e.g., 'Express Shipping', 'Curbside Pickup').
description	string	No	Complete context for buyer decision (e.g., 'Arrives Dec 12-15 via FedEx').
carrier	string	No	Carrier name (for shipping).
earliest_fulfillment_time	string	No	Earliest fulfillment date.
latest_fulfillment_time	string	No	Latest fulfillment date.
totals	Array[Total Response]	Yes	Fulfillment option totals breakdown.

Item¶

Item Create Request¶

Name	Type	Required	Description
id	string	Yes	Should be recognized by both the Platform, and the Business. For Google it should match the id provided in the "id" field in the product feed.

Item Update Request¶

Name	Type	Required	Description
id	string	Yes	Should be recognized by both the Platform, and the Business. For Google it should match the id provided in the "id" field in the product feed.

Item Response¶

Name	Type	Required	Description
id	string	Yes	Should be recognized by both the Platform, and the Business. For Google it should match the id provided in the "id" field in the product feed.
title	string	Yes	Product title.
price	integer	Yes	Unit price in minor (cents) currency units.
image_url	string	No	Product image URI.

Line Item¶

Line Item Create Request¶

Name	Type	Required	Description
item	Item Create Request	Yes
quantity	integer	Yes	Quantity of the item being purchased.

Line Item Update Request¶

Name	Type	Required	Description
id	string	No
item	Item Update Request	Yes
quantity	integer	Yes	Quantity of the item being purchased.
parent_id	string	No	Parent line item identifier for any nested structures.

Line Item Response¶

Name	Type	Required	Description
id	string	Yes
item	Item Response	Yes
quantity	integer	Yes	Quantity of the item being purchased.
totals	Array[Total Response]	Yes	Line item totals breakdown.
parent_id	string	No	Parent line item identifier for any nested structures.

Link¶

Name	Type	Required	Description
type	string	Yes	Type of link. Well-known values: `privacy_policy`, `terms_of_service`, `refund_policy`, `shipping_policy`, `faq`. Consumers SHOULD handle unknown values gracefully by displaying them using the `title` field or omitting the link.
url	string	Yes	The actual URL pointing to the content to be displayed.
title	string	No	Optional display text for the link. When provided, use this instead of generating from type.

Well-Known Link Types¶

Businesses SHOULD provide all relevant links for the transaction. The following are the recommended well-known types:

Type	Description
`privacy_policy`	Link to the business's privacy policy
`terms_of_service`	Link to the business's terms of service
`refund_policy`	Link to the business's refund policy
`shipping_policy`	Link to the business's shipping policy
`faq`	Link to the business's frequently asked questions

Businesses MAY define custom types for domain-specific needs. Platforms SHOULD handle unknown types gracefully by displaying them using the title field or omitting them.

Message¶

This object MUST be one of the following types: Message Error, Message Warning, Message Info.

Message Error¶

Name	Type	Required	Description
type	string	Yes	Constant = error. Message type discriminator.
code	string	Yes	Error code. Possible values include: missing, invalid, out_of_stock, payment_declined, requires_sign_in, requires_3ds, requires_identity_linking. Freeform codes also allowed.
path	string	No	RFC 9535 JSONPath to the component the message refers to (e.g., $.items[1]).
content_type	string	No	Content format, default = plain. Enum: `plain`, `markdown`
content	string	Yes	Human-readable message.
severity	string	Yes	Declares who resolves this error. 'recoverable': agent can fix via API. 'requires_buyer_input': merchant requires information their API doesn't support collecting programmatically (checkout incomplete). 'requires_buyer_review': buyer must authorize before order placement due to policy, regulatory, or entitlement rules (checkout complete). Errors with 'requires_' severity contribute to 'status: requires_escalation'. Enum:* `recoverable`, `requires_buyer_input`, `requires_buyer_review`

Message Info¶

Name	Type	Required	Description
type	string	Yes	Constant = info. Message type discriminator.
path	string	No	RFC 9535 JSONPath to the component the message refers to.
code	string	No	Info code for programmatic handling.
content_type	string	No	Content format, default = plain. Enum: `plain`, `markdown`
content	string	Yes	Human-readable message.

Message Warning¶

Name	Type	Required	Description
type	string	Yes	Constant = warning. Message type discriminator.
path	string	No	JSONPath (RFC 9535) to related field (e.g., $.line_items[0]).
code	string	Yes	Warning code. Machine-readable identifier for the warning type (e.g., final_sale, prop65, fulfillment_changed, age_restricted, etc.).
content	string	Yes	Human-readable warning message that MUST be displayed.
content_type	string	No	Content format, default = plain. Enum: `plain`, `markdown`

Payment¶

Payment Create Request¶

Name	Type	Required	Description
selected_instrument_id	string	No	The id of the currently selected payment instrument from the instruments array. Set by the agent when submitting payment, and echoed back by the merchant in finalized state.
instruments	Array[Payment Instrument]	No	The payment instruments available for this payment. Each instrument is associated with a specific handler via the handler_id field. Handlers can extend the base payment_instrument schema to add handler-specific fields.

Payment Update Request¶

Name	Type	Required	Description
selected_instrument_id	string	No	The id of the currently selected payment instrument from the instruments array. Set by the agent when submitting payment, and echoed back by the merchant in finalized state.
instruments	Array[Payment Instrument]	No	The payment instruments available for this payment. Each instrument is associated with a specific handler via the handler_id field. Handlers can extend the base payment_instrument schema to add handler-specific fields.

Payment Response¶

Name	Type	Required	Description
handlers	Array[Payment Handler Response]	Yes	Processing configurations that define how payment instruments can be collected. Each handler specifies a tokenization or payment collection strategy.
selected_instrument_id	string	No	The id of the currently selected payment instrument from the instruments array. Set by the agent when submitting payment, and echoed back by the merchant in finalized state.
instruments	Array[Payment Instrument]	No	The payment instruments available for this payment. Each instrument is associated with a specific handler via the handler_id field. Handlers can extend the base payment_instrument schema to add handler-specific fields.

Payment Handler Response¶

Name	Type	Required	Description
id	string	Yes	The unique identifier for this handler instance within the payment.handlers. Used by payment instruments to reference which handler produced them.
name	string	Yes	The specification name using reverse-DNS format. For example, dev.ucp.delegate_payment.
version	string	Yes	Handler version in YYYY-MM-DD format.
spec	string	Yes	A URI pointing to the technical specification or schema that defines how this handler operates.
config_schema	string	Yes	A URI pointing to a JSON Schema used to validate the structure of the config object.
instrument_schemas	Array[string]	Yes
config	object	Yes	A dictionary containing provider-specific configuration details, such as merchant IDs, supported networks, or gateway credentials.

Payment Instrument¶

This object MUST be one of the following types: Card Payment Instrument.

Card Payment Instrument¶

Name	Type	Required	Description
id	string	Yes	A unique identifier for this instrument instance, assigned by the Agent. Used to reference this specific instrument in the 'payment.selected_instrument_id' field.
handler_id	string	Yes	The unique identifier for the handler instance that produced this instrument. This corresponds to the 'id' field in the Payment Handler definition.
type	string	Yes	Constant = card. Indicates this is a card payment instrument.
billing_address	Postal Address	No	The billing address associated with this payment method.
credential	Payment Credential	No
brand	string	Yes	The card brand/network (e.g., visa, mastercard, amex).
last_digits	string	Yes	Last 4 digits of the card number.
expiry_month	integer	No	The month of the card's expiration date (1-12).
expiry_year	integer	No	The year of the card's expiration date.
rich_text_description	string	No	An optional rich text description of the card to display to the user (e.g., 'Visa ending in 1234, expires 12/2025').
rich_card_art	string	No	An optional URI to a rich image representing the card (e.g., card art provided by the issuer).

Payment Credential¶

This object MUST be one of the following types: Token Credential Response, Card Credential.

Token Credential Response¶

Name	Type	Required	Description
type	string	Yes	The specific type of token produced by the handler (e.g., 'stripe_token').
token	string	Yes	The token value.

Card Credential¶

Name	Type	Required	Description
type	any	Yes	Constant = card. The credential type identifier for card credentials.
card_number_type	string	Yes	The type of card number. Network tokens are preferred with fallback to FPAN. See PCI Scope for more details. Enum: `fpan`, `network_token`, `dpan`
number	string	No	Card number.
expiry_month	integer	No	The month of the card's expiration date (1-12).
expiry_year	integer	No	The year of the card's expiration date.
name	string	No	Cardholder name.
cvc	string	No	Card CVC number.
cryptogram	string	No	Cryptogram provided with network tokens.
eci_value	string	No	Electronic Commerce Indicator / Security Level Indicator provided with network tokens.

Postal Address¶

Name	Type	Required	Description
extended_address	string	No	An address extension such as an apartment number, C/O or alternative name.
street_address	string	No	The street address.
address_locality	string	No	The locality in which the street address is, and which is in the region. For example, Mountain View.
address_region	string	No	The region in which the locality is, and which is in the country. Required for applicable countries (i.e. state in US, province in CA). For example, California or another appropriate first-level Administrative division.
address_country	string	No	The country. Recommended to be in 2-letter ISO 3166-1 alpha-2 format, for example "US". For backward compatibility, a 3-letter ISO 3166-1 alpha-3 country code such as "SGP" or a full country name such as "Singapore" can also be used.
postal_code	string	No	The postal code. For example, 94043.
first_name	string	No	Optional. First name of the contact associated with the address.
last_name	string	No	Optional. Last name of the contact associated with the address.
full_name	string	No	Optional. Full name of the contact associated with the address (if first_name or last_name fields are present they take precedence).
phone_number	string	No	Optional. Phone number of the contact associated with the address.

Response¶

Name	Type	Required	Description
name	string	Yes	Stable capability identifier in reverse-domain notation (e.g., dev.ucp.shopping.checkout). Used in capability negotiation.
version	string	Yes	Capability version in YYYY-MM-DD format.
spec	string	No	URL to human-readable specification document.
schema	string	No	URL to JSON Schema for this capability's payload.
extends	string	No	Parent capability this extends. Present for extensions, absent for root capabilities.
config	object	No	Capability-specific configuration (structure defined by each capability).

Total¶

Total Response¶

Name	Type	Required	Description
type	string	Yes	Type of total categorization. Enum: `items_discount`, `subtotal`, `discount`, `fulfillment`, `tax`, `fee`, `total`
display_text	string	No	Text to display against the amount. Should reflect appropriate method (e.g., 'Shipping', 'Delivery').
amount	integer	Yes	If type == total, sums subtotal - discount + fulfillment + tax + fee. Should be >= 0. Amount in minor (cents) currency units.

UCP Response Checkout¶

Name	Type	Required	Description
version	string	Yes	UCP protocol version in YYYY-MM-DD format.
capabilities	Array[Response]	Yes	Active capabilities for this response.

Order Confirmation¶

Name	Type	Required	Description
id	string	Yes	Unique order identifier.
permalink_url	string	Yes	Permalink to access the order on merchant site.
